Product information
SIMATIC DP, ET200 PRO fail-safe electronic module with part number 6ES7148-4FC00-0AB0 for 4/8 F-DI/4 F-DO.
Detailed Parameters
Module type:Fail-safe electronic module
Product family/system:SIMATIC DP, ET200 PRO
Fail-safe digital input/output configuration:4/8 F-DI/4 F-DO
Supply voltage:24 V DC
Output current:2 A
Safety integration:PROFIsafe
Overall width:90 mm
Safety category:up to Category 4 (EN 954-1)
Safety integrity level:up to SIL3 (IEC61508)
Performance level:up to PLE (ISO13849)
Engineering Context
The module is part of SIMATIC DP ET200 PRO and is designated as a fail-safe electronic module.
It provides a fail-safe configuration of 4/8 F-DI/4 F-DO with 24 V DC and up to 2 A output current.
Fail-safe operation is integrated via PROFIsafe with safety targets up to Category 4 (EN 954-1), SIL3 (IEC61508), and PLE (ISO13849).
FAQ
1. Which SIMATIC family does the module belong to?
It belongs to SIMATIC DP, ET200 PRO.
2. What is the fail-safe input/output configuration?
It is specified as 4/8 F-DI/4 F-DO.
3. What supply and output current are specified?
The module is specified for 24 V DC with 2 A.
4. What fail-safe mechanism is specified?
The module is specified with PROFIsafe.
5. What overall width is specified?
The overall width is 90 mm.
6. What maximum safety targets are specified?
Up to Category 4 (EN 954-1), SIL3 (IEC61508), and PLE (ISO13849).
