SIMATIC DP ET200 PRO fail-safe electronic module F-switch PROFIsafe with part number 6ES7148-4FS00-0AB0 provides fail-safe switching of the backplane busbars and includes additional fail-safe digital inputs.
Detailed Parameters
Product family/system:SIMATIC DP, ET200 PRO
Module designation:Fail-safe electronic module F-switch
Safety system:PROFIsafe
Fail-safe outputs:3 fail-safe PP-switching outputs for safe switching of the backplane busbars (2L +, F0, F1)
Fail-safe inputs:2 fail-safe digital inputs
Module width:45mm
Functional safety capability:up to Category 4 (EN 954-1)/ SIL3 (IEC61508)/ PLE (ISO13849)
Engineering Context
The fail-safe electronic module F-switch PROFIsafe is part of the SIMATIC DP ET200 PRO system.
It provides safe switching of the backplane busbars via 3 fail-safe PP-switching outputs (2L +, F0, F1).
The module includes 2 fail-safe digital inputs and supports functional safety up to Category 4 (EN 954-1)/ SIL3 (IEC61508)/ PLE (ISO13849).
FAQ
1. What is the product family and module type for part number 6ES7148-4FS00-0AB0?
It is a SIMATIC DP ET200 PRO fail-safe electronic module F-switch.
2. How many fail-safe PP-switching outputs does the module provide and for what purpose?
It provides 3 fail-safe PP-switching outputs for safe switching of the backplane busbars (2L +, F0, F1).
3. How many fail-safe digital inputs are included?
The module includes 2 fail-safe digital inputs.
4. Which safety designation is associated with this module?
PROFIsafe.
5. What is the maximum stated safety category/performance?
Up to Category 4 (EN 954-1)/ SIL3 (IEC61508)/ PLE (ISO13849).
6. What is the module width?
45mm.
