Product information
SIMATIC ET 200SP digital output module with part number 6ES7132-6BF00-0CA0 for 8 digital outputs (DQ) of 24VDC/0.5A High Feature; includes channel diagnostics for short-circuit and wire break and channel fault indication.
Detailed Parameters
Product family:SIMATIC ET 200SP
Module type:digital output module
Designation:DQ 8x 24VDC/0.5A High Feature
Output type:source output PNP
Number of channels:8
Channel diagnostics for:Short-circuit and wire break
Channel fault indication:channel fault LED
Supply voltage indication:supply voltage
Suitable for:BU type A0
Color code:CC02
Packing unit:1 unit
Engineering Context
The module provides 8x digital outputs as DQ 8x 24VDC/0.5A High Feature within SIMATIC ET 200SP.
It is configured for source output using PNP output type.
Channel diagnostics cover short-circuit and wire break and are complemented by a channel fault LED.
FAQ
1. What is the module designation for part number 6ES7132-6BF00-0CA0?
DQ 8x 24VDC/0.5A High Feature.
2. How many output channels does this SIMATIC ET 200SP digital output module provide?
8 channels.
3. What output type does the module use?
Source output PNP.
4. Which channel diagnostics are included?
Short-circuit and wire break.
5. Is a channel fault LED provided?
Yes, channel fault LED is included.
6. Which BU type is this module suitable for?
BU type A0.
