SIMATIC ET 200SP Digital output module for DQ 8x 24V DC/0,5A standard source output (PNP, P-switching); Part number 6ES7132-6BF01-0BA0.
Detailed Parameters
Product family:SIMATIC ET 200SP
Module type:Digital output module
Designation:DQ 8x 24V DC/0,5A Standard
Output type:Source output (PNP, P-switching)
Packing unit:1 piece
Fits to:BU-type A0
Colour code:CC02
Substitute value output:Yes
Module diagnostics:Short-circuit to L+ and ground; wire break; supply voltage
Engineering Context
The SIMATIC ET 200SP Digital output module provides DQ 8x 24V DC/0,5A standard source outputs (PNP, P-switching).
The module includes substitute value output and module diagnostics for short-circuit to L+ and ground, wire break, and supply voltage.
The module fits to BU-type A0 and uses colour code CC02.
