SIMATIC DP electronics module for ET200S, part number 6ES7135-4FB01-0AB0, with 2 AO U.
Detailed Parameters
Product type:Spare part
System family:SIMATIC DP
Module designation:Electronics module f. ET200S
Number of outputs:2 AO U
Width:15 mm
Output range:+/-10V
Resolution:13 bit+sign; 1..5 V; 12 bit
Cycle time:Less than 1 ms with SF LED (group fault)
Engineering Context
The SIMATIC DP electronics module is intended for use with ET200S as an electronics module f. ET200S.
The module provides 2 AO U analog outputs with a specified output range of +/-10V.
The cycle time is specified as less than 1 ms with SF LED (group fault).
FAQ
1. What is the part number and module family?
Part number 6ES7135-4FB01-0AB0; SIMATIC DP electronics module f. ET200S.
2. How many analog outputs does the module provide?
2 AO U.
3. What is the module width?
15 mm width.
4. What output voltage range is specified?
+/-10V.
5. What resolution and analog range are specified?
13 bit+sign; 1..5 V; 12 bit.
6. What is the specified cycle time?
Cycle time less than 1 ms with SF LED (group fault).
