Product information
SIMATIC DP electronic modules for ET 200 PRO 4 AO I High Feature; part number 6ES7145-4GF00-0AB0.
Detailed Parameters
Product family:SIMATIC DP
System / module platform:ET 200 PRO
Module designation:4 AO I High Feature
Output signal type:I
Current ranges:+-20 mA; 0…20 mA; 4-20mA
Channel diagnostics:Channel diagnostics
Included components:incl. bus module
Ordering note:Connection module IO 6ES7194-4..00-0AA0 order separately
Engineering Context
The SIMATIC DP electronic module is intended for ET 200 PRO 4 AO I High Feature configuration.
The module provides current output signal ranges of +-20 mA, 0…20 mA, and 4-20mA.
Channel diagnostics are included for the module.
FAQ
1. What is the Siemens product family and module designation for 6ES7145-4GF00-0AB0?
It is part of the SIMATIC DP product family and is designated for ET 200 PRO as 4 AO I High Feature.
2. Which analog current output ranges are provided?
The module supports +-20 mA, 0…20 mA, and 4-20mA.
3. Does the module include channel diagnostics?
Yes, it includes channel diagnostics.
4. Is the connection module included in the scope of delivery?
No. The Connection module IO 6ES7194-4..00-0AA0 must be ordered separately.
5. What is included with the module regarding bus components?
It includes a bus module (incl. bus module).
