SIMATIC DP interface module IM 151-3 PN HF (Part number: 6ES7151-3BA23-0AB0) for ET 200S provides a PROFIBUS DP interface with up to 100 Mbit/s transmission rate and connection for up to 63 I/O modules.
Detailed Parameters
Product type:Spare part
System:SIMATIC DP
Module designation:Interface module IM 151-3 PN HF
For:ET 200S
Transmission rate:100 Mbit/s max.
I/O modules supported:63 I/O modules up to
Bus connections:2x bus connections via RJ45
Termination module:Incl. termination module
Max. width:up to 2 m width can be connected
Engineering Context
The IM 151-3 PN HF interface module IM 151-3 PN HF is intended for ET 200S in a SIMATIC DP setup.
The module supports operation with a transmission rate of 100 Mbit/s max. and up to 63 I/O modules.
Two bus connections via RJ45 are provided, including a termination module.
