Product information
SIMATIC DP connection module for the PROFINET interface module for ET 200 PRO; Part number 6ES7194-4AG00-0AA0.
Detailed Parameters
Product family:SIMATIC DP
Type:Connection module for PROFINET interface module
Subrack/system:ET 200 PRO
Fiber connectors:Connection 2xSCRJ FO
Plug-in connector type:2x push-pull plug-in connectors
Field designation:for PROFINET PN
Engineering Context
Use this SIMATIC DP connection module as the connection interface for a PROFINET interface module in an ET 200 PRO configuration.
The module provides optical fiber connections via connection 2xSCRJ FO.
Connectivity is implemented using 2x push-pull plug-in connectors for PROFINET PN.
FAQ
1. What is the function of 6ES7194-4AG00-0AA0?
It is a SIMATIC DP connection module for a PROFINET interface module for ET 200 PRO.
2. Which system is this connection module intended for?
ET 200 PRO.
3. What connector type and count are provided?
Connection 2xSCRJ FO with 2x push-pull plug-in connectors.
4. For which PROFINET designation is the module provided?
PROFINET PN.
