LOGO! logic module LOGO! 24RCEO with part number 6ED1052-2HB08-0BA1 provides a modularly expandable solution with Ethernet and integrated web server, including data log and user-defined web pages.
Detailed Parameters
Product designation:LOGO! 24RCEO
Module type:logic module
Display:without display
Power supply / I/O:24 V DC/24 V AC
Output type:relay
Number of digital inputs (DI):8
Number of digital outputs (DO):4
Memory:memory 400 blocks
Expansion:modularly expandable
Ethernet:Ethernet
Web server:integrated web server
Data log:data log
User-defined web pages:user-defined web pages
Memory card:standard microSD card for LOGO! Soft Comfort V8.3 or higher
Project execution:older projects executable
Connection:cloud connection in all LOGO! 8.3 basic units
Engineering Context
LOGO! 24RCEO logic module with relay outputs provides 8 digital inputs and 4 digital outputs for controller application logic.
The module includes Ethernet with an integrated web server, supporting data logging and user-defined web pages.
Program memory capacity is specified as 400 blocks and it supports modular expansion.
FAQ
1. What type of module is 6ED1052-2HB08-0BA1?
It is a LOGO! 24RCEO logic module.
2. Does 6ED1052-2HB08-0BA1 include a display?
No, it is without display.
3. What are the I/O counts and output type for LOGO! 24RCEO?
It has 8 DI and 4 DO with relay output.
4. What power supply/I/O voltage is specified?
The power supply / I/O is 24 V DC/24 V AC.
5. What memory capacity is specified?
The memory is 400 blocks.
6. What networking and web features are included?
It supports Ethernet and has an integrated web server with data log and user-defined web pages.
7. How is the microSD card used and what LOGO! Soft Comfort version is supported?
It uses a standard microSD card for LOGO! Soft Comfort V8.3 or higher.
