SIMATIC S7-1200 Digital I/O SM 1223 (Part Number: 6ES7223-1QH32-0XB0) is designed as an SM 1223 module with 8 digital inputs and 8 relay digital outputs.
Detailed Parameters
Product family:SIMATIC S7-1200
Module designation:Digital I/O SM 1223
Digital inputs:8 DI
Digital inputs voltage type:120/230 V AC
Digital outputs:8 DO
Output type:relay
Output current:2 A
Engineering Context
The module Digital I/O SM 1223 in SIMATIC S7-1200 provides a combination of 8 digital inputs and 8 relay-based digital outputs.
The digital inputs are specified for 120/230 V AC signal level.
The digital outputs are relay outputs rated at 2 A.
FAQ
1. What product family does 6ES7223-1QH32-0XB0 belong to?
6ES7223-1QH32-0XB0 belongs to SIMATIC S7-1200.
2. How many digital inputs and what input voltage type are provided?
The module provides 8 DI for 120/230 V AC.
3. How many digital outputs are provided, and what is their output type?
The module provides 8 DO with relay outputs.
4. What is the relay output current rating?
The relay outputs are rated for 2 A.
5. What is the module designation of this part number?
The module designation is Digital I/O SM 1223.
