SIMATIC S7-200 CN CPU 224 Compact device (part number 6ES7214-1AD23-0XB8) with DC power supply and DI/DO configuration for PROFIBUS DP expandable systems; CE approval applies to this S7-200 CN product.
Detailed Parameters
Product type:spare part
Product family:SIMATIC S7-200 CN
Device:CPU 224 Compact
Power supply:DC power supply
DI:14 DI DC
DO:10 DO DC
PROG memory:8/12 KB progr.
Data memory:8 KB data
Expansion:PROFIBUS DP expandable
Approval:CE approval
Engineering Context
The SIMATIC S7-200 CN CPU 224 Compact device is provided as a spare part for SIMATIC S7-200 CN systems.
The CPU 224 Compact configuration includes 14 DI DC and 10 DO DC with DC power supply.
System configuration includes PROFIBUS DP expandable capability depending on system setup.
FAQ
1. What product family and device designation are associated with part number 6ES7214-1AD23-0XB8?
The part number 6ES7214-1AD23-0XB8 is for SIMATIC S7-200 CN CPU 224 Compact.
2. What power supply type does the CPU 224 Compact use?
It is specified as DC power supply.
3. What are the configured digital input and output counts and signal types?
It provides 14 DI DC and 10 DO DC.
4. What memory capacities are specified for the CPU 224 Compact?
It is specified as 8/12 KB progr. and 8 KB data.
5. Which expansion is supported for the SIMATIC S7-200 CN CPU 224 Compact?
It is specified as PROFIBUS DP expandable.
6. What approval is stated for this SIMATIC S7-200 CN product?
The information provided states that this S7-200 CN product only has CE approval.
