SIMATIC S7-200 CN Digital I/O EM 223 provides digital I/O for use with part number 6ES7223-1PM22-0XA8 in an S7-200 CN system configured with an S7-22X CPU.
Detailed Parameters
Spare part:Yes
Product family:SIMATIC S7-200 CN
Module:Digital I/O EM 223
Intended for:only for S7-22X CPU
Digital inputs (DI):32
DI input voltage:24 V DC
DI type:sink/source
Digital outputs (DO):32 DO relay
Output current per channel:2 A/channel
Approvals:CE
Engineering Context
Digital I/O EM 223 is intended only for S7-22X CPU in the SIMATIC S7-200 CN product family.
The module provides 32 digital inputs at 24 V DC configured for sink/source operation.
The module provides 32 DO relay outputs with 2 A/channel.
