SIMATIC S7-300 SM 322 provides a digital output spare part with isolated groups of 16 and 64 DO.
Detailed Parameters
Module:SIMATIC S7-300 digital output SM 322
Isolation grouping:isolated in groups of 16
Digital outputs (DO):64 DO
Output voltage:24 V DC
Source output total current:2 A/group
Maximum source output total current per module:8 A/module
Terminal blocks:8 A/module terminal blocks 6ES7392-1.N00-0AA0
Required cables:cable 6ES7392-4…0-0AA0 required
Engineering Context
SM 322 is used as a SIMATIC S7-300 digital output module with outputs isolated in groups of 16.
The module provides 64 DO with 24 V DC source outputs specified as 2 A/group and 8 A/module.
Terminal blocks 6ES7392-1.N00-0AA0 and cable 6ES7392-4…0-0AA0 are required as stated.
FAQ
1. What product family and function does 6ES7322-1BP50-0AA0 belong to?
6ES7322-1BP50-0AA0 is a SIMATIC S7-300 digital output module (SM 322) spare part.
2. How many digital outputs (DO) are provided?
The module provides 64 DO.
3. What is the output voltage for the SM 322?
The output voltage is 24 V DC.
4. How is the module output isolation grouped?
Outputs are isolated in groups of 16.
5. What are the specified source output total currents?
The specified source output total current is 2 A/group and 8 A/module.
6. Which terminal blocks and cables are required?
The required terminal blocks are 6ES7392-1.N00-0AA0 and the required cable is 6ES7392-4…0-0AA0.
