SIMATIC S7-300 digital module SM 323 (isolated) with part number 6ES7323-1BH01-0AA0 provides 8 DI and 8 DO with 24 V DC and 1x 20-pole connection.
Detailed Parameters
Product family:SIMATIC S7-300
Module type:digital module SM 323
Isolation:isolated
Inputs:8 DI
Outputs:8 DO
Supply voltage:24 V DC
Total current:0.5 A total current
Current:2 A
Connector:1x 20-pole
Part type:spare part
Engineering Context
The SM 323 digital module supports isolated digital input and digital output functions with 8 DI and 8 DO.
The module is designed for 24 V DC operation within the SIMATIC S7-300 system configuration.
A 1x 20-pole connector is provided for the module interface.
FAQ
1. What is the product family and module designation for part number 6ES7323-1BH01-0AA0?
It is SIMATIC S7-300 digital module SM 323.
2. How many digital inputs and digital outputs does SM 323 provide?
It provides 8 DI and 8 DO.
3. What supply voltage is specified for the module?
24 V DC.
4. Is the SM 323 module isolated?
Yes, it is isolated.
5. What connector type is specified?
1x 20-pole.
6. Is part number 6ES7323-1BH01-0AA0 listed as a spare part?
Yes, it is specified as a spare part.
