SIMATIC S7-300 analog output SM 332 (part number 6ES7332-7ND02-0AB0) is designed for isolated by channel analog output and supports isochronous mode improved bus cycle times.
Detailed Parameters
Product type:analog output SM 332
Isolation:isolated by channel
Number of analog output channels:4 AO
Resolution:16 bit
Voltage output ranges:0-10 V, 1-5 V, +/-10 V
Current output ranges:+/-20 mA, 0/4-20 mA
Pole count:20-pole
Bus cycle times (isochronous mode):isochronous mode improved bus cycle times for the isochronous mode
Spare part information:spare part
Engineering Context
The SM 332 is used as an analog output module within the SIMATIC S7-300 system.
The module provides isolated-by-channel analog output to support multiple configured output signal ranges.
For isochronous operation, the module is described as supporting improved bus cycle times for the isochronous mode.
FAQ
1. What module family and function does 6ES7332-7ND02-0AB0 belong to?
It belongs to SIMATIC S7-300 and is an analog output SM 332.
2. How many analog output channels are available?
The module has 4 AO.
3. Is the analog output isolated by channel?
Yes, it is isolated by channel.
4. What resolution does the analog output module provide?
It provides 16 bit resolution.
5. Which voltage output ranges are supported?
0-10 V, 1-5 V, and +/-10 V.
6. Which current output ranges are supported?
+/-20 mA and 0/4-20 mA.
7. What is the bus cycle time behavior for isochronous mode?
It supports isochronous mode improved bus cycle times for the isochronous mode.
