Product information
SIPLUS ET 200SP BU20-P12+A4+0B (Part Number: 6AG1193-6BP20-7BB0) is based on 6ES7193-6BP20-0BB0 with conformal coating and includes push-in terminals plus 4 AUX terminals.
Detailed Parameters
Based on:6ES7193-6BP20-0BB0
Conformal coating:Yes
Operating temperature:-40…+70 °C
BU type:B0
Terminal type:push-in terminals
AUX terminals:4
AUX terminal bridging:bridged to the left
Dimensions (WxH):20 mm x 117 mm
Engineering Context
SIPLUS ET 200SP BU20-P12+A4+0B (6AG1193-6BP20-7BB0) is based on 6ES7193-6BP20-0BB0 with conformal coating.
The device is configured as BU type B0 and uses push-in terminals.
It provides 4 AUX terminals bridged to the left and has dimensions of WxH: 20 mm x 117 mm.
FAQ
1. What is the basis of SIPLUS ET 200SP BU20-P12+A4+0B with Part Number 6AG1193-6BP20-7BB0?
It is based on 6ES7193-6BP20-0BB0.
2. Does 6AG1193-6BP20-7BB0 include conformal coating?
Yes, it is based with conformal coating.
3. What is the specified operating temperature range for 6AG1193-6BP20-7BB0?
-40…+70 °C.
4. What terminal type and AUX terminal configuration are provided by 6AG1193-6BP20-7BB0?
It has push-in terminals with 4 AUX terminals, bridged to the left.
5. What are the dimensions (WxH) of 6AG1193-6BP20-7BB0?
20 mm x 117 mm.
