Product information
SIPLUS ET 200SP DI 8x48VUC TX rail based digital input module, part number 6AG2131-6CF00-4AU0, based on 6ES7131-6CF00-0AU0 with conformal coating.
Detailed Parameters
Part number:6AG2131-6CF00-4AU0
Product family / designation:SIPLUS ET 200SP DI 8x48VUC TX
Based on:6ES7131-6CF00-0AU0
Module type:digital input module
Channels:8
Input voltage / signal:48VUC
Rail:TX rail
Conformal coating:yes
Suitable for BU type:U0
Color code:CC20
Operating temperature:-40…+70 °C
OT4:OT4 with ST1/2 (+85 °C for 10 minutes)
Module diagnostics:module diagnostics
Engineering Context
SIPLUS ET 200SP DI 8x48VUC TX rail based digital input module provides 8 digital input channels for 48VUC signals.
The module is based on 6ES7131-6CF00-0AU0 and includes conformal coating.
Module diagnostics are provided and the module is suitable for BU type U0 with color code CC20.
FAQ
1. What is the function of 6AG2131-6CF00-4AU0?
It is a SIPLUS ET 200SP DI 8x48VUC TX rail based digital input module.
2. How many input channels and what signal level does it support?
It has 8 channels and is specified for 48VUC.
3. Is conformal coating included?
Yes, the rail based module is based on 6ES7131-6CF00-0AU0 with conformal coating.
4. What temperature range is specified for operation?
The operating temperature is -40…+70 °C.
5. What are the OT4/ST1/2 conditions?
OT4 with ST1/2 (+85 °C for 10 minutes).
6. Does the module include diagnostics?
Yes, module diagnostics are included.
