Product information
SIPLUS ET 200SP CPU 1512SP F-1 PN (Part Number: 6AG2512-1SK01-1AB0) is a rail-based central processing unit based on 6ES7512-1SK01-0AB0 with conformal coating for use in ET 200SP system configurations.
Detailed Parameters
Order base:based on 6ES7512-1SK01-0AB0
Conformal coating:with conformal coating
Operating temperature range:-25…+60 °C
OT1 / ST1/2 temperature:OT1 with ST1/2 (+70 °C for 10 minutes)
Memory (work memory):300 KB for program
Memory (data):1 MB for data
Interface (1st interface):PROFINET IRT with 3-port switch
1st interface port type:PROFINET IRT with 3-port switch
Bit performance:48 ns bit performance
Required accessories:SIMATIC Memory Card required
Required accessories:BusAdapter required for port 1 and 2
Engineering Context
The CPU 1512SP F-1 PN integrates a central processing unit with work memory of 300 KB for program and 1 MB for data.
The 1st interface is configured as PROFINET IRT using a 3-port switch.
A SIMATIC Memory Card and a BusAdapter for port 1 and 2 are required for operation in the specified configuration.
FAQ
1. What is the product family and designation for part number 6AG2512-1SK01-1AB0?
SIPLUS ET 200SP CPU 1512SP F-1 PN.
2. On which base unit is this CPU based?
It is based on 6ES7512-1SK01-0AB0.
3. What is the work memory size for program and data?
300 KB for program and 1 MB for data.
4. What is the 1st interface type for this CPU?
PROFINET IRT with 3-port switch.
5. Which accessories are required for operation?
SIMATIC Memory Card required; BusAdapter required for port 1 and 2.
6. What temperature range is specified for this CPU?
-25…+60 °C, with OT1 and ST1/2 (+70 °C for 10 minutes).
