SIPLUS S7-1200 SM 1222 module (Part Number: 6AG1222-1BH32-4XB0) provides digital output 16 DQ based on 6ES7222-1BH32-0XB0 with conformal coating.
Detailed Parameters
Based on:6ES7222-1BH32-0XB0
Conformal coating:Yes
Operating temperature:-20…+60 °C
Output type:Digital output 16 DQ
Output voltage:24 V DC
Output technology:Transistor
Output current:0.5 A
Engineering Context
SIPLUS S7-1200 SM 1222 with Part Number 6AG1222-1BH32-4XB0 is a digital output 16 DQ module based on 6ES7222-1BH32-0XB0.
The module uses conformal coating and is intended for operation over -20…+60 °C.
It provides transistor digital outputs with 24 V DC output voltage and 0.5 A output current.
FAQ
1. What module family and function does 6AG1222-1BH32-4XB0 belong to?
6AG1222-1BH32-4XB0 belongs to SIPLUS S7-1200 SM 1222 and provides digital output 16 DQ.
2. Is 6AG1222-1BH32-4XB0 based on a 6ES7222-1BH32 variant?
Yes. It is based on 6ES7222-1BH32-0XB0.
3. What are the electrical output characteristics of the module?
It provides 24 V DC transistor digital outputs with an output current of 0.5 A.
4. What temperature range is specified for this module?
-20…+60 °C.
5. Does 6AG1222-1BH32-4XB0 include conformal coating?
Yes, it is stated as with conformal coating.
