Ordering this product
Check the full part number and required version against your equipment. Add any electrical or connection requirements when contacting us.
Product information
SIPLUS S7-300 CPU 315F-2PN/DP (Part Number: 6AG1315-2FJ14-2AY0) provides central processing unit functionality with 512 KB work memory, based on 6ES7315-2FJ14-0AB0 and with conformal coating for -25…+60 °C operation.
Detailed Parameters
Product type:spare part
System family:SIPLUS S7-300
CPU designation:CPU 315F-2PN/DP
Based on:6ES7315-2FJ14-0AB0
Conformal coating:Yes
Operating temperature:-25…+60 °C
Work memory:512 KB
1st interface:MPI/DP
1st interface data rate:12 Mbps
2nd interface:Ethernet PROFINET
Ethernet PROFINET:2-port switch
Micro Memory Card:required
Engineering Context
Use 6AG1315-2FJ14-2AY0 as a SIPLUS S7-300 CPU 315F-2PN/DP spare part based on 6ES7315-2FJ14-0AB0.
The CPU provides central processing with 512 KB work memory and an operating range of -25…+60 °C when used with conformal coating.
The CPU includes 1st interface MPI/DP (12 Mbps) and 2nd interface Ethernet PROFINET with a 2-port switch, with Micro Memory Card required.
FAQ
1. What is the product family and CPU designation for part number 6AG1315-2FJ14-2AY0?
It is a SIPLUS S7-300 spare part with CPU designation CPU 315F-2PN/DP.
2. Based on which reference does 6AG1315-2FJ14-2AY0 operate?
It is based on 6ES7315-2FJ14-0AB0.
3. What operating temperature range is specified?
-25…+60 °C.
4. How much work memory does the CPU provide?
512 KB work memory.
5. What interfaces are included and what is the MPI/DP data rate?
1st interface MPI/DP with 12 Mbps, and 2nd interface Ethernet PROFINET with a 2-port switch.
6. Is a Micro Memory Card required?
Yes, Micro Memory Card required.
