SIPLUS S7-300 SM 322 32 DO with conformal coating, part number 6AG1322-1BL00-2AA0, is designed as a digital output isolated module with 32 DO and 24 V DC, using 1x 40-pole connection.
Detailed Parameters
Spare part:Yes
Based on:6ES7322-1BL00-0AA0
Conformal coating:Yes
Temperature range:-25…+70 °C
Output type:Digital output isolated
Number of digital outputs (DO):32 DO
Output supply:24 V DC
Output current:0.5 A
Connector:1x 40-pole
Total current:4 A/group (16 A/module)
Engineering Context
SIPLUS S7-300 SM 322 32 DO provides isolated digital output functionality for systems using the referenced base designation 6ES7322-1BL00-0AA0.
The module is configured with 32 DO and a 1x 40-pole connection arrangement.
The specified operating temperature range is -25…+70 °C.
FAQ
1. What is the product family and function of 6AG1322-1BL00-2AA0?
It is a SIPLUS S7-300 SM 322 32 DO digital output isolated module.
2. How many digital outputs does the module provide?
The module provides 32 DO.
3. What output supply and current values are specified?
The module is specified for 24 V DC output supply and 0.5 A output current.
4. What connector format is used?
It uses 1x 40-pole.
5. Is the module an isolated digital output?
Yes, the digital output is specified as isolated.
6. What is the stated temperature range?
The stated temperature range is -25…+70 °C.
7. Is 6AG1322-1BL00-2AA0 specified as a spare part?
Yes, it is specified as a spare part.
