SIPLUS S7-300 SM 322 Digital Output Module (8 DO) with conformal coating; part number 6AG1322-5FF00-4AB0.
Detailed Parameters
Spare part:Yes
Product family:SIPLUS S7-300
Module type:SM 322
Digital output channels:8 DO
Output type:digital output isolated
Conformal coating:with conformal coating
Ambient temperature:0…+60 °C
Channel/terminal concept:with single-point grounding/channel
Failure mode:selectable failure mode
Rated output voltage:120/230 V AC
Output current:2 A
Reference basis:based on 6ES7322-5FF00-0AB0
Connector/terminal:1x 40-pole
Engineering Context
SIPLUS S7-300 SM 322 provides 8 isolated digital outputs as a spare part based on 6ES7322-5FF00-0AB0.
The module is suitable for applications with selectable failure mode and single-point grounding/channel.
Use the module in systems where ambient temperature is within 0…+60 °C.
FAQ
1. What module family and function does 6AG1322-5FF00-4AB0 belong to?
It belongs to SIPLUS S7-300 SM 322 and is a digital output module (8 DO).
2. How many digital output channels are provided?
8 DO.
3. Are the digital outputs isolated?
Yes, digital output isolated.
4. What rated output voltage and output current are specified?
120/230 V AC and 2 A.
5. What ambient temperature range is specified?
0…+60 °C.
6. What grounding and failure-mode options are specified?
Single-point grounding/channel and selectable failure mode.
7. Is a conformal coating included?
Yes, with conformal coating.
