SIPLUS S7-1500 CPU 1513-1 PN (Part number: 6AG1513-1AL02-7AB0) based on 6ES7513-1AL02-0AB0 with conformal coating, designed for operation over -40…+70 °C.
Detailed Parameters
Basis:based on 6ES7513-1AL02-0AB0
Conformal coating:with conformal coating
Operating temperature:-40…+70 °C
Heat sink:heat sink
Power supply:no PS usable
Work memory for program:300 KB
Work memory for data:1.5 MB
1st interface:PROFINET IRT with 2-port switch
Bit performance:40 ns
SIMATIC Memory Card:SIMATIC Memory Card required (spare part display: 6AG1591-1AB00-2AA0)
Engineering Context
The central processing unit provides work memory for program (300 KB) and data (1.5 MB).
The CPU includes a 1st interface based on PROFINET IRT with a 2-port switch.
The specified heat sink and conformal coating are provided for operation across -40…+70 °C.
FAQ
1. What is the basis and designation of 6AG1513-1AL02-7AB0?
6AG1513-1AL02-7AB0 is SIPLUS S7-1500 CPU 1513-1 PN, based on 6ES7513-1AL02-0AB0.
2. What work memory is available for program and data?
The CPU has work memory of 300 KB for program and 1.5 MB for data.
3. Which interface is provided and what is its configuration?
The 1st interface is PROFINET IRT with 2-port switch.
4. What operating temperature range is specified?
-40…+70 °C.
5. Is a power supply (PS) usable with this CPU?
No PS usable.
6. Is a SIMATIC Memory Card required, and what spare part display number is listed?
Yes, SIMATIC Memory Card is required; spare part display: 6AG1591-1AB00-2AA0.
