SIPLUS S7-1500 DI 16x110VDC HF digital input module, part number 6AG2521-7EH00-4AB0, with conformal coating for rail-based installation.
Detailed Parameters
Product family:SIPLUS S7-1500
Module type:digital input module
Input voltage:110VDC
HF input:yes
Conformal coating:yes
Installation type:TX rail based
Channel count:16
Channel grouping:in groups of 1
Input delay:0.05 … 20 ms
Input type:3 (IEC 61131)
Diagnostics:yes
Hardware interrupts:yes
Ambient operating temperature range:-40…+70 °C
OT4:OT4
ST1/2 temperature condition:+85 °C for 10 minutes
Base type reference:based on 6ES7521-7EH00-0AB0
Engineering Context
The SIPLUS S7-1500 DI 16x110VDC HF digital input module provides 16 digital inputs for 110VDC HF input signals in groups of 1.
The module supports configurable input delay of 0.05 … 20 ms and an input type 3 according to IEC 61131.
Diagnostics and hardware interrupts are available for the module in the controller system configuration.
FAQ
1. What is the module type for part number 6AG2521-7EH00-4AB0?
It is a SIPLUS S7-1500 digital input module (DI 16x110VDC HF).
2. How many digital input channels does 6AG2521-7EH00-4AB0 provide?
It provides 16 channels in groups of 1.
3. What input voltage and input behavior are specified for this module?
The module is specified for 110VDC high-frequency (HF) inputs and uses input type 3 (IEC 61131).
4. What input delay range is supported?
The input delay is specified as 0.05 … 20 ms.
5. Does the module include diagnostics and hardware interrupts?
Yes, diagnostics and hardware interrupts are provided.
6. What temperature conditions are specified?
The specified ambient operating temperature range is -40…+70 °C, with OT4 and ST1/2 (+85 °C for 10 minutes).
