Product information
SIPLUS SIMOCODE pro V basic unit 2, part number 6AG1010-1AU00-4AA0, based on 3UF7010-1AU00-0 with conformal coating, designed for operation with US: 110-240 V AC/DC and expandable by expansion modules.
Detailed Parameters
Product base:based on 3UF7010-1AU00-0
Conformal coating:yes
Operating temperature:-25…+60 °C
PROFIBUS DP interface data rate:12 Mbps
Interface:RS-485
I/O count:4 I/3 O
I/O parameterization:freely parameterizable
US:110-240 V AC/DC
Thermistor connection input:yes
Relay output type:monostable
Expandability:expandable by expansion modules
Engineering Context
The SIPLUS SIMOCODE pro V basic unit 2 provides a PROFIBUS DP interface at 12 Mbps using RS-485.
The input for thermistor connection supports parameterizable operation with US: 110-240 V AC/DC.
Monostable relay outputs are provided with 4 I/3 O that are freely parameterizable and can be expanded via expansion modules.
FAQ
1. What is the operating temperature range of 6AG1010-1AU00-4AA0?
-25…+60 °C.
2. Which communication interface and data rate are supported?
PROFIBUS DP interface 12 Mbps; RS-485.
3. How many inputs and outputs does the basic unit provide, and can they be parameterized?
4 I/3 O with freely parameterizable I/O.
4. What supply range is specified as US?
110-240 V AC/DC.
5. Does the device include an input for thermistor connection?
Yes.
6. What type of relay outputs are provided?
Monostable relay outputs.
7. Can the basic unit be expanded?
Yes, expandable by expansion modules.
