Product information
SIPLUS ET 200SP CM PTP communications module (Part Number: 6AG1137-6AA01-7BA0) for serial connection via RS-422, RS-485 and RS-232 with conformal coating.
Detailed Parameters
Based on:6ES7137-6AA01-0BA0
Conformal coating:Yes
Operating temperature range:-40…+70 °C
Interface / serial connection:RS-422, RS-485 and RS-232
Supported protocols / functions:Freeport; 3964 (R); USS; MODBUS RTU master, slave
Max. data rate:250 Kbit/s
Suitable for:BU type A0
Engineering Context
The module provides serial communications for RS-422, RS-485 and RS-232 within SIPLUS ET 200SP CM PTP.
Protocol handling includes Freeport, 3964 (R), USS, and MODBUS RTU in master and slave operation modes.
The SIPLUS ET 200SP CM PTP module is suitable for BU type A0 and supports a max. data rate of 250 Kbit/s.
FAQ
1. What is the product designation and product family for Part Number 6AG1137-6AA01-7BA0?
It is a SIPLUS ET 200SP CM PTP communications module.
2. Which serial interfaces are supported by the module?
RS-422, RS-485 and RS-232.
3. Which protocols are supported?
Freeport; 3964 (R); USS; MODBUS RTU master, slave.
4. What is the maximum communication data rate?
Max. 250 Kbit/s.
5. What temperature range is specified for this module?
-40…+70 °C.
6. Is the module conformally coated?
Yes, based on the provided conformal coating information.
