Product information
SIPLUS S7-1500 CPU 1513-1 PN with part number 6AG1513-1AM03-7AB0 provides conformal coating operation for -40…+70 °C and includes the specified CPU work memory and PROFINET IRT interface configuration; SIMATIC Memory Card required.
Detailed Parameters
Part Number:6AG1513-1AM03-7AB0
Based On:6ES7513-1AM03-0AB0
Product Family / System:SIPLUS S7-1500
CPU Designation:CPU 1513-1 PN
Conformal Coating:Yes
Ambient Temperature Range:-40…+70 °C
Work Memory (Program):600 KB
Work Memory (Data):2.5 MB
1st Interface:PROFINET IRT
1st Interface – Ports:2-port switch
Bit Performance:25 ns
Memory Card Requirement:SIMATIC Memory Card required
Engineering Context
The SIPLUS S7-1500 CPU 1513-1 PN at part number 6AG1513-1AM03-7AB0 is based on 6ES7513-1AM03-0AB0 and includes conformal coating for operation over -40…+70 °C.
The CPU provides work memory of 600 KB for program and 2.5 MB for data.
The 1st interface is PROFINET IRT with a 2-port switch and 25 ns bit performance.
FAQ
1. What is the designation of the CPU for part number 6AG1513-1AM03-7AB0?
CPU 1513-1 PN.
2. What is the ambient temperature range for this CPU?
-40…+70 °C.
3. Which interface is listed as the 1st interface and how many ports does it include?
PROFINET IRT with 2-port switch.
4. What work memory sizes are specified for program and data?
600 KB for program and 2.5 MB for data.
5. Is a SIMATIC Memory Card required?
Yes, SIMATIC Memory Card required.
6. What bit performance is specified for this CPU?
25 ns bit performance.
