Ordering this product
Check the full part number and required version against your equipment. Add any electrical or connection requirements when contacting us.
Product information
SIMATIC IPC527G (Box PC) with part number 6AG4025-0CE30-3AA0, designed for operation with a 100/240 V AC power supply and an Intel Core i5-6500 processor.
Detailed Parameters
Product family:SIMATIC IPC527G (Box PC)
Part number:6AG4025-0CE30-3AA0
Ethernet ports:2x Gigabit Ethernet (IE/PN)
Display interfaces:1x display port, 1x VGA
USB ports:4x USB3.0
Serial interfaces:2x RS232/485/422 (can be selected)
Power supply:100/240 V AC
Processor:Core i5-6500 (4C/4T, 3.2 (3.6) GHz, 6 MB cache)
Memory:16 GB DDR4
Storage:256 GB SSD
Operating system:Windows 10 Enterprise 2016 LTSB MUI (de,en,fr,es,it), 64 bit
Processor support (statement provided):For Pentium/Core i5
PCIe slots:1 x PCIe x16
Expansions:Without specific expansions
Engineering Context
The SIMATIC IPC527G (Box PC) is provided with 2x Gigabit Ethernet (IE/PN) for network connection.
The Box PC includes two serial interfaces that can be selected as RS232/485/422.
The system is configured with 4x USB3.0 and video outputs via 1x display port and 1x VGA.
FAQ
1. What is the product family and function designation for part number 6AG4025-0CE30-3AA0?
SIMATIC IPC527G (Box PC).
2. How many Gigabit Ethernet interfaces are included and what designation is used?
2x Gigabit Ethernet (IE/PN).
3. Which display interfaces are provided?
1x display port and 1x VGA.
4. How many USB3.0 ports are available?
4x USB3.0.
5. What serial interfaces are supported and how many channels are provided?
2x RS232/485/422 (can be selected).
6. What power supply input is specified?
100/240 V AC.
7. Which processor, storage, and memory are specified?
Core i5-6500 (4C/4T, 3.2 (3.6) GHz, 6 MB cache), 256 GB SSD, and 16 GB DDR4.
8. What operating system is included?
Windows 10 Enterprise 2016 LTSB MUI (de,en,fr,es,it), 64 bit.
