Product information
SIMATIC IPC427E (Microbox PC) supports 6AG4141-7BB02-0DA0 and is configured with HD graphic onboard, 4x USB V3.0 (high current), and 3x Gbit Ethernet (IE/PN) for use with an industrial 24 V DC power supply.
Detailed Parameters
Part number:6AG4141-7BB02-0DA0
Product family:SIMATIC IPC427E (Microbox PC)
Graphics:HD graphic onboard
USB ports:4x USB V3.0 (high current)
PCIe:Without PCIe
Processor:XEON E3-1505L
Ethernet ports:3x Gbit Ethernet (IE/PN)
Mounting:Mounting onto standard rail
Memory:8 GB
RS232/RS485:Without RS232/485
Operating system:WIN Embedded Standard 7 SP1, English, 64-bit
Replaceable mass storage:Without replaceable mass storage
Storage:256 GB Eco SSD
SIMATIC software:Without SIMATIC software
Power supply:24 V DC industrial power supply
Engineering Context
The SIMATIC IPC427E (Microbox PC) variant 6AG4141-7BB02-0DA0 provides HD graphic onboard and 4x USB V3.0 (high current).
The configuration includes 3x Gbit Ethernet (IE/PN) while being specified as without RS232/485 and without PCIe.
The unit is intended for mounting onto standard rail and operation with a 24 V DC industrial power supply.
FAQ
1. What product family does 6AG4141-7BB02-0DA0 belong to?
6AG4141-7BB02-0DA0 belongs to SIMATIC IPC427E (Microbox PC).
2. Which graphics and USB interfaces are included?
It has HD graphic onboard and 4x USB V3.0 (high current).
3. How many Ethernet interfaces are specified, and what type are they?
It includes 3x Gbit Ethernet (IE/PN).
4. Is RS232/485 and PCIe included?
No, it is specified as without RS232/485 and without PCIe.
5. What memory and storage are specified?
It is specified with 8 GB and 256 GB Eco SSD, without replaceable mass storage.
6. What operating system and power supply are specified?
It uses WIN Embedded Standard 7 SP1, English, 64-bit, and requires a 24 V DC industrial power supply.
