KP8 empty front for mounting standard 22.5 mm operator controls; part number 6AV3688-3XY38-3AX0 is also suitable for installation in an Extension Unit of all 15\.
Detailed Parameters
Format:KP8
Mounting:Easy mounting of standard 22.5 mm operator controls
Product type:Empty front
Intended use:For setting up modular operator panels
Installation:Also suitable for installation in Extension Unit of all 15\
Engineering Context
The KP8 empty front supports mounting of standard 22.5 mm operator controls for modular operator panel configurations.
The design is intended to simplify setup of modular operator panels using a KP8-format front.
The product is suitable for installation in an Extension Unit of all 15\, depending on the system configuration.
FAQ
1. What is 6AV3688-3XY38-3AX0?
6AV3688-3XY38-3AX0 is an empty front in KP8 format for easy mounting of standard 22.5 mm operator controls.
2. Which operator control size does the empty front support?
It is designed for mounting standard 22.5 mm operator controls.
3. Is 6AV3688-3XY38-3AX0 suitable for modular operator panel setups?
Yes. It is ideal for setting up modular operator panels.
4. Can the empty front be installed in an Extension Unit?
Yes. It is also suitable for installation in the Extension Unit of all 15\.
