SIMATIC Flat Panel Monitor V2 Extended V2 host module with part number 6AV7860-3EH00-0AA0 for HDBaseT V2 transceiver connections using DisplayPort and USB to HDBaseT, with 24 V power supply.
Detailed Parameters
Product family:SIMATIC Flat Panel Monitor V2 Extended V2
Product designation:host module
Transceiver interface:HDBaseT V2 transceiver
Video interface:DisplayPort
Signal interface:USB to HDBaseT
Power supply:24 V
Engineering Context
The SIMATIC Flat Panel Monitor V2 Extended V2 host module 6AV7860-3EH00-0AA0 is designed as an HDBaseT V2 transceiver interface for DisplayPort and USB to HDBaseT.
The module includes a 24 V power supply for operation within the SIMATIC Flat Panel Monitor V2 Extended V2 system configuration.
Depending on system configuration, the DisplayPort and USB-to-HDBaseT interfaces are used for signal connection to the HDBaseT V2 transceiver.
FAQ
1. What product family and designation does 6AV7860-3EH00-0AA0 belong to?
6AV7860-3EH00-0AA0 belongs to SIMATIC Flat Panel Monitor V2 Extended V2 and is a host module.
2. Which transceiver interface is provided by this host module?
It provides an HDBaseT V2 transceiver.
3. What input/output interfaces are listed for signal handling?
DisplayPort and USB to HDBaseT are listed.
4. What power supply is specified for 6AV7860-3EH00-0AA0?
A 24 V power supply is specified.
