Product information
SIMATIC DP, connection ET 200M IM 153-2 High Feature, part number 6ES7153-2BA10-0XB0, is provided as a spare part for ET 200M. It is intended for max. 12 S7-300 modules and includes redundancy capability and time stamping suitable for isochronous mode. New features include up to 12 modules can be used, Device Initiative for Drive ES and Switch ES, expanded quantity structure for HART auxiliary variables, and operation of the 64-channel modules 32 signals/slot. Compatibility notes are to be observed in the manual.
Detailed Parameters
Product type:spare part
Product family:SIMATIC DP
Connection:ET 200M
Designation:IM 153-2 High Feature
Maximum modules:max. 12 S7-300 modules
Redundancy capability:yes
Time stamping:suitable for isochronous mode
New features:up to 12 modules can be used; Device Initiative for Drive ES and Switch ES; expanded quantity structure for HART auxiliary variables; operation of the 64-channel modules 32 signals/slot
Engineering Context
The ET 200M IM 153-2 High Feature is used as a connection for ET 200M in the SIMATIC DP system.
The device supports up to 12 S7-300 modules and redundancy capability.
Compatibility notes are to be observed in the manual.
FAQ
1. What is the product family of 6ES7153-2BA10-0XB0?
SIMATIC DP.
2. What is the designation of this ET 200M connection?
IM 153-2 High Feature.
3. How many S7-300 modules are supported?
Up to 12 S7-300 modules.
4. Does the product support redundancy capability?
Yes.
5. Is time stamping included?
Yes, time stamping is suitable for isochronous mode.
