Ordering this product
Check the full part number and required version against your equipment. Add any electrical or connection requirements when contacting us.
Product information
SIMATIC DP connection module for PROFINET interface module ET 200 PRO IM154-3 PN HF; part number 6ES7194-4AL00-0AA0.
Detailed Parameters
Product:SIMATIC DP
Function:Connection module for PROFINET interface module ET 200 PRO IM154-3 PN HF
Connectors:M12 M12-L S
Port configuration:2x M12-D and 2x M12-L
Engineering Context
The connection module is designed for use with the PROFINET interface module ET 200 PRO IM154-3 PN HF in a SIMATIC DP system.
The module provides a specified M12 port configuration with 2x M12-D and 2x M12-L connectors.
The connector type for the module is specified as M12 M12-L S.
FAQ
1. What is the product family of part 6ES7194-4AL00-0AA0?
The product family is SIMATIC DP.
2. What is the main function of 6ES7194-4AL00-0AA0?
It is a connection module for the PROFINET interface module ET 200 PRO IM154-3 PN HF.
3. Which connector types are provided?
It provides M12 M12-L S.
4. How many M12-D and M12-L ports are included?
It includes 2x M12-D and 2x M12-L.
5. Which PROFINET interface module is this connection module intended for?
It is intended for PROFINET interface module ET 200 PRO IM154-3 PN HF.
