Product information
SM 1231 TC (SIMATIC S7-1200) with part number 6ES7231-5QD32-0XB0 is an analog input module designed for 4 AI thermocouples.
Detailed Parameters
Product family:SIMATIC S7-1200
Module type:SM 1231 TC
Input type:Analog input
Channel count:4 AI
Thermocouple channels:4 AI thermocouples
Engineering Context
Use SM 1231 TC within the SIMATIC S7-1200 system to acquire thermocouple signals as analog input.
The module is specified with 4 AI thermocouples for channelized analog input acquisition.
Select this module configuration when 4 thermocouple analog input channels are required for SIMATIC S7-1200.
FAQ
1. What product family does 6ES7231-5QD32-0XB0 belong to?
6ES7231-5QD32-0XB0 belongs to SIMATIC S7-1200.
2. What is the module designation for 6ES7231-5QD32-0XB0?
The module designation is SM 1231 TC.
3. What signal type does SM 1231 TC provide?
SM 1231 TC provides an analog input.
4. How many thermocouple input channels does this module support?
It is specified as 4 AI thermocouples.
