SIPLUS G120 CU240E-2 USS E-type Control Unit (part number 6AG1244-0BB12-2BA1) with Safety Integrated STO, conformal coating, and USS protocol over RS-485 interface.
Detailed Parameters
Based on:6SL3244-0BB12-1BA1
Conformal coating:with conformal coating
Temperature range:-20…+55 °C
Control Unit:CU240E-2 USS E-type
Safety Integrated:STO
Interface:RS-485
USS protocol:USS
DI:6
DQ:3
AI:2
AQ:2
PTC/KTY interface (max.):1F-DI PTC/KTY
USB interface:USB
Memory card interface:SD/MMC
Degree of protection:IP20
Power Module:without Power Module
Engineering Context
SIPLUS G120 CU240E-2 USS E-type Control Unit provides Safety Integrated STO in the system configuration.
The RS-485 interface supports USS protocol operation with defined signal counts (DI, DQ, AI, AQ).
USB and SD/MMC interfaces are provided, and the unit is delivered without Power Module.
FAQ
1. What is the product family and designation for part number 6AG1244-0BB12-2BA1?
SIPLUS G120 CU240E-2 USS Control Unit CU240E-2 USS E-type.
2. Which safety function is integrated in the CU240E-2 USS E-type?
Safety Integrated STO.
3. What interface is used for USS protocol communication?
RS-485 interface with USS protocol.
4. How many DI, DQ, AI, and AQ signals are specified?
DI: 6, DQ: 3, AI: 2, AQ: 2.
5. Does the product include a Power Module?
No, it is without Power Module.
6. What is the specified degree of protection?
IP20.
