SIPLUS ET 200S EM 2AQ I analog input module (Part Number: 6AG1135-4GB01-2AB0) provides standard-based 2AQ I input functionality with conformal coating for operation over -25…+70 °C.
Detailed Parameters
Based on:6ES7135-4GB01-0AB0
Conformal coating:Yes
Operating temperature:-25…+70 °C
Signal range:+/-20 mA
Resolution:13 bit+sign
Current input range:4..20 mA
Resolution (4..20 mA):13 bit
Cycle time:less than 1 ms
SF LED:group fault
Engineering Context
SIPLUS ET 200S EM 2AQ I provides analog input functionality in standard configuration based on 6ES7135-4GB01-0AB0.
With conformal coating, the module is specified for -25…+70 °C operation.
The input performance includes a cycle time of less than 1 ms and indicates group fault via SF LED.
FAQ
1. What is the product family and designation for part 6AG1135-4GB01-2AB0?
SIPLUS ET 200S EM 2AQ I.
2. On which base design is the module configured?
It is the standard based on 6ES7135-4GB01-0AB0.
3. Does this module include conformal coating?
Yes, it is specified with conformal coating.
4. What operating temperature range is specified for the module?
-25…+70 °C.
5. What analog current signal ranges and resolutions are specified?
+/-20 mA with 13 bit+sign, and 4..20 mA with 13 bit.
6. What cycle time is specified and how is the SF LED described?
Cycle time is less than 1 ms, and the SF LED indicates group fault.
