SIPLUS ET 200SP IM155-6PN HF T1 rail based on 6ES7155-6AU01-0CN0 spare part (6AG2155-6AU01-1CN0) is provided with conformal coating and includes the server module (6AG1193-6PA00-7AA0).
Detailed Parameters
Conformal coating:Yes
Ambient temperature range:-25…+60 °C
OT1:With ST1/2 (+70 °C for 10 minutes)
Interface module ports:2-port interface module
Slot requirement:1 slot for BusAdapter
Max. I/O modules:max. 64 I/O modules
Max. ET 200AL modules:16 ET 200AL modules
Redundancy:S2 redundancy
Hot swap:multi hot swap
Cycle time:0.25 ms
Mode:isochronous mode
Optional PN strain relief:Optional
Including server module:6AG1193-6PA00-7AA0
Rail based on:6ES7155-6AU01-0CN0
Engineering Context
The SIPLUS ET 200SP IM155-6PN HF T1 rail spare part is based on 6ES7155-6AU01-0CN0 and supports conformal coating.
The configuration is a 2-port interface module using 1 slot for BusAdapter with support for up to 64 I/O modules and 16 ET 200AL modules.
It is specified for S2 redundancy and multi hot swap operation with a cycle time of 0.25 ms in isochronous mode.
FAQ
1. What is the part number of this SIPLUS spare part?
The part number is 6AG2155-6AU01-1CN0.
2. Which rail and Siemens designation is this spare part based on?
It is a SIPLUS ET 200SP IM155-6PN HF T1 rail based on 6ES7155-6AU01-0CN0.
3. What interface and slot configuration does the module use?
It is a 2-port interface module using 1 slot for BusAdapter.
4. How many I/O modules and ET 200AL modules can be connected?
It supports max. 64 I/O modules and 16 ET 200AL modules.
5. What redundancy and hot swap functions are specified?
It supports S2 redundancy and multi hot swap.
6. What is the specified operating time and mode?
It is specified with a cycle time of 0.25 ms and in isochronous mode.
7. What temperature range is specified for the product?
The specified ambient temperature range is -25…+60 °C, with OT1 and ST1/2 (+70 °C for 10 minutes).
8. Is the product supplied with a server module?
Yes, it includes the server module 6AG1193-6PA00-7AA0.
