Product information
SIPLUS G120 PM240-2 drive 6AG1210-1PE32-2AL0 with conformal coating and integrated class A filter and integrated braking chopper, based on 6SL3210-1PE32-5AL0, FSF design and IP20 protection without CU and operating unit released as of CU FW version V4.7 HF8.
Detailed Parameters
Based on:6SL3210-1PE32-5AL0
Conformal coating:Yes
Integrated class A filter:Yes
Integrated braking chopper:Yes
Rated power:132 kW
Operating voltage:380-480 V 3 AC (+10/-20%)
Frequency range:47-63 Hz
Overload (high):110 kW at 200% for 3 s; 150% for 57 s; 100% for 240 s
Overload (low):132 kW at 150% for 3 s; 110% for 57 s; 100% for 240 s
Operating temperature range:-20…+50 °C
Dimensions (HxWxD):708x 305x 357
FSF design:FSF design
Degree of protection:IP20
Without CU and operating unit:Without CU and operating unit
CU FW version release:Released as of CU FW version V4.7 HF8
Engineering Context
The product is a SIPLUS G120 PM240-2 FSF drive based on 6SL3210-1PE32-5AL0 with conformal coating.
The drive integrates a class A filter and an integrated braking chopper for 380-480 V 3 AC systems.
FSF design and IP20 degree of protection are specified for operation within -20…+50 °C.
FAQ
1. What is the rated power and supply range for 6AG1210-1PE32-2AL0?
Rated power is 132 kW, for 380-480 V 3 AC (+10/-20%) at 47-63 Hz.
2. Does 6AG1210-1PE32-2AL0 include an integrated class A filter and braking chopper?
Yes. It includes an integrated class A filter and an integrated braking chopper.
3. What degree of protection and operating temperature range are specified?
Degree of protection is IP20 and the operating temperature range is -20…+50 °C.
4. What FSF designation is provided for this drive?
The product is specified with FSF design.
5. Is the CU and operating unit included with 6AG1210-1PE32-2AL0?
No. It is specified without CU and operating unit.
6. As of which CU FW version is the product released?
Released as of CU FW version V4.7 HF8.
