Product information
SIPLUS ET 200SP CPU 1512SP-1 PN rail based on 6ES7512-1DM03-0AB0. Part number 6AG2512-1DM03-1AB0 includes PROFINET IRT with 3-port switch and requires SIMATIC Memory Card and BusAdapter for port 1 and port 2.
Detailed Parameters
Product base:PN rail based on 6ES7512-1DM03-0AB0
Conformal coating:OT2 / ST1/2
Temperature range (OT2):-40…+55 °C
Temperature (ST1/2):70 °C for 10 minutes
Work memory for program:400 KB
Work memory for data:2 MB
1st interface:PROFINET IRT with 3-port switch
Bit performance:25 ns
Required:SIMATIC Memory Card
Required for port 1 and port 2:BusAdapter
Engineering Context
SIPLUS ET 200SP CPU 1512SP-1 PN rail is intended as a central processing unit for program and data execution.
The CPU provides a 1st interface as PROFINET IRT with a 3-port switch.
A SIMATIC Memory Card is required, and a BusAdapter is required for port 1 and port 2.
FAQ
1. What is the product family and function of 6AG2512-1DM03-1AB0?
It is a SIPLUS ET 200SP CPU 1512SP-1 PN rail based central processing unit.
2. What work memory capacities are specified for the CPU?
The work memory is 400 KB for program and 2 MB for data.
3. Which interface is specified for the CPU and how many ports are included?
The 1st interface is PROFINET IRT with a 3-port switch.
4. What are the conformal coating temperature ratings (OT2 and ST1/2)?
OT2 is -40…+55 °C, and ST1/2 is 70 °C for 10 minutes.
5. What accessories are required for operation?
SIMATIC Memory Card is required, and a BusAdapter is required for port 1 and port 2.
